The Eclipse® octagonal cantilever umbrella places a generous canopy beyond its aluminum mast, preserving open space for dining and lounge furniture beneath. Extruded aluminum ribs and stainless-steel hardware support the frame, while crank lift, full-circle rotation and Infinity Tilt provide precise shade adjustment. Frame finishes and acrylic canopy color options bring a composed architectural presence to luxury outdoor living and hospitality settings.
Key Features
-
Product Type: Outdoor cantilever umbrella
-
Shape: Octagonal
-
Material: Corrosion-resistant aluminum frame, extruded aluminum ribs and stainless-steel hardware
-
Canopy Material: Acrylic fabric options; selected by configuration
-
Finish / Color: Selectable frame finishes and canopy colors
-
Operation: Commercially rated crank lift
-
Rotation: 360-degree mast rotation with 24 locking positions at 15-degree intervals
-
Tilt System: Infinity Tilt with automatic locking
-
Construction Details:
- 1.2-inch by 0.6-inch tulip ribs with 2.5 mm wall thickness
- 3.3-inch by 5-inch extruded aluminum mast
-
Mounting Options:
- Compatible freestanding cantilever base
- Compatible direct-mount installation
-
Residential & Commercial Suitability: Ground-level residential and hospitality outdoor spaces
-
Included Components: Black polyester protective cover
-
Compatibility Notes: A correctly specified cantilever base or structural mount is required; confirm the selected package and wind stabilization kit with BOXHILL
Dimensions
11' Octagonal Model
-
Canopy Span: 11 ft.
-
Height: 111.4 in.
-
Hub Clearance: 80.7 in.
-
Closed Clearance: 41.7 in.
-
Open Depth: 142.5 in.
-
Weight: 116 lbs.
13' Octagonal Model
-
Canopy Span: 13 ft.
-
Height: 111.4 in.
-
Hub Clearance: 81.9 in.
-
Closed Clearance: 32 in.
-
Open Depth: 163.8 in.
-
Weight: 123 lbs.
Design / Use Context
Resort pool decks and generous residential lounge areas gain flexible shade without a center pole interrupting the furniture plan. The octagonal Eclipse® complements curved seating and conversation groups, with mast rotation allowing the shade to shift between adjacent areas. Reserve space for the full operating sweep, the selected base and safe guest circulation before finalizing the layout.
Care & Maintenance
-
Canopy Cleaning: Remove loose dirt with a soft brush. Use low-pressure fresh water and solvent-free mild soap in lukewarm water, then rinse thoroughly. Follow the instructions for the selected fabric before stain treatment.
-
Drying & Storage: Allow the canopy to air-dry completely before prolonged closure, covering or storage. If it must be closed while wet, reopen it to dry as soon as conditions allow.
-
Mast & Moving Parts: Rinse salt, dirt and debris from the mast, slider tracks and rotation area with fresh water. Inspect the installation fittings regularly and follow the owner’s manual for adjustment or lubrication.
-
Folding & Covering: Pull fabric panels clear of the ribs after closing, fold them neatly, then secure the canopy strap. Use the protective cover for extended periods without use.
-
Wind Stabilization: Follow the supplied instructions for fitting and removing stabilization bars. The bars are used only with the canopy level and locked; remove them before tilting or closing.
-
Wind & Unattended Use: Close and secure the umbrella when unattended, in strong winds or before severe weather. A published wind rating is a tested-condition guide, not a guarantee against damage.
Frequently Asked Questions
What is the difference between cantilever and center-pole shade?
The Eclipse® supports its canopy from an offset mast, leaving the furniture area beneath free of a center pole.
How can I adjust the shade?
The canopy has crank lift, Infinity Tilt and full-circle mast rotation. Rotation locks in 24 positions, spaced 15 degrees apart. Allow room for the complete operating sweep.
Does it include a base?
A compatible cantilever base or structural mount is required. Confirm whether that support is included in your selected order; the umbrella specification alone does not establish a complete installed package. A standard center-pole base is not interchangeable.
Are a protective cover and wind kit supplied?
The current specifications list a black polyester cover. Confirm the wind stabilization kit in your selected package with BOXHILL before ordering. If supplied, install and remove it according to the owner’s manual.
Can I leave the umbrella open in windy weather?
The published guide is 30 mph for this canopy type under the supplier’s specified test conditions. It does not apply while tilted and does not provide wind-damage warranty coverage. Close and secure the umbrella when unattended or in strong winds; site conditions and anchoring matter.
Is it suitable for a rooftop installation?
The supplier’s published warranties and wind ratings do not apply to rooftops or elevated patios above ground level. Discuss any elevated installation with BOXHILL before ordering; ground-level ratings should not be used to approve it.
How do I care for the canopy?
Clean gently with a soft brush, mild solvent-free soap and low-pressure water, then rinse and air-dry completely. Use the selected fabric’s care instructions for stain removal.
What warranty applies?
Limited coverage depends on the model, fabric, residential or commercial use, and correct installation and care. Confirm the written terms for your configuration with BOXHILL. Wind damage and rooftop/elevated installations are excluded from the published coverage.
Where can I review shipping, returns and cancellations?
This umbrella is made to order. The current product terms state that cancellations and change-of-mind returns are not accepted. Review the Shipping Policy, Return Policy and Terms & Conditions before ordering, and contact BOXHILL promptly about a damaged or defective delivery.
